NEW EQUIPMENT

TEI Rock Drills

Western Shotcrete

TEI Rock Drills

Safety Equipment

Attachment Drills

Drill Component

Limited Access Drills

Tescar

Western Shotcrete

TEI Rock Drills

CF1, CF2,  CF2.5, CF2.5 Plus, CF2.5 Compact, CF3 S,

CFS3 S Plus, CF4, CF6 & CF8

TT5, TT7 & TT9, TT8

Western Shotcrete

Western Shotcrete

Western Shotcrete

Warrior X400

Warrior X500

TEI ROCK DRILLS

TEI Safety Equipment

Dust Suppression System

DS10851

  • 100 gal (378 l) water tank
  • 2” air supply connection
  • 350 PSI (24 bar) max air supply
  • Dry weight: 500 lb (227 kg)


Brochure




DS26851

DS26851

  • 26 gal (95 l) water tank
  • 1 ½” air supply connections
  • 250 PSI max air supply
  • Dry weight: 275 lb (60 kg)


Brochure

Safety Handler & Protective Safety Cover

HCC10X Hydraulic Casing Safety Handler

 The HCC10X Hydraulic Casing Handler is a TEI Rock Drill attachment for excavators, designed to ensure safe handling of drill pipe and casing in field applications. It attaches easily to most 8-ton and larger excavators. With the ability to grasp and position ‘5-10’ length of pipe and casing, it allows for accurate and concentric placement over the drill rig.

  • Does not modify the excavator
  • Uses the auxiliary hydraulics
  • Mounts to most any excavator
  • Picks Casing and Pipe Simultaneously
  • Promote Safety on your job site
  • Keeps string centered inside casing
  • Patent pending

Brochure









HCC16X Hydraulic Casing Safety Handler

HCC16X Hydraulic Casing Safety Handler

 The HCC16X is designed to help contrac- tors work quickly, safely, and efficiently on the jobsite. The unique claws help the oper-ator to clamp onto various sized pipe with-out racks, or the safety hazard of having a helper in the work zone.

A true attachment, the HCC16X does not modify the excavator in any way. It uses auxiliary hydraulics of the excavator. The HCC16X picks up casing and drill pipe simultaneously, keeping them concentric. with two 360-degree positioners allow the operator to work in both vertical and hori- zontal planes. A programmed controller is used for smooth operation under loads.



Brochure

TEI Attachment Drills

HCM – Skid Steer Drill Attachment

hem25ed extended excavator drill attachment

HCM – Skid Steer Drill Attachment

The TEI Skid Steer Drill Attachment is designed to maximize the utility of this popular loader. Includes a universal mounting plate that conveniently connects to most skid steer models.


Available with either our patented hydraulic drifters or the RDS line of rotary heads. Capable of most drilling techniques including grouted hollow bar soil nails and micropiles, augers, coring, rock drilling and mud rotary application.



Brochure

HEM – Excavator Drill Attachment

hem25ed extended excavator drill attachment

HCM – Skid Steer Drill Attachment

Most popular TEI drilling attachment

  • Mounts on 20–25-ton excavators
  • No additional hydraulic plumbing required
  • Used with both rotary and percussion drill heads
  • 11.75 – 12.75 feet of drill travel








Brochure

hem25ed extended excavator drill attachment

hem25ed extended excavator drill attachment

hem25ed extended excavator drill attachment

 TEI can reconfigure existing rock drills for use when longer strokes are required. Our extended attachment provides the longest stroke possible while still allowing the drill to be transported while attached to the excavator. The mast offers a 25 ft (7.6 m) stroke with a 15 ft (4.6 m) rod-adder. The rod-adder has a positive grip that keeps the drill rod or auger in place regardless of the drilling angle. The TEI Extended Excavator Rock Drill can install a 40 ft (12.2 m) soil nail or micropile with only one operator.



Brochure

MME – Mini Excavator Drill Attachment

MME – Mini Excavator Drill Attachment

hem25ed extended excavator drill attachment

Lightweight aluminum mast feed

  • Mounts on 5-10-ton excavators
  • Uses both rotary and percussion drill heads
  • 10.5 feet of drill travel
  • Single 4” Hydraulic foot clamp







Brochure

MEM – mid-weight excavator mount

MME – Mini Excavator Drill Attachment

hemh - hydraulic excavator attachment

  • Mounts on 12-15 ton excavators
  • Uses both rotary and percussion drill heads
  • 11 feet of drill travel
  • Single 6.5" hydraulic clamp








Brochure

hemh - hydraulic excavator attachment

MME – Mini Excavator Drill Attachment

hemh - hydraulic excavator attachment

 Largest and most powerful TEI excavator drill

  • Mounts on 25-30 ton excavators
  • Attach and detach with ease
  • 13 feet of drill travel
  • Used with either rotary or percussion drill heads







Brochure

TEI Drill Component

Diesel Power Units

DM360 Diesel Power Unit

Supports the 300 series of drifters and

rotary heads


  • 35 GPM @ 2250 PSI (132 lpm) of hydraulic flow


  • 77.2 HP (57.6 kW) Deutz Turbo tier III engine


  • 2202 lbs (999 kgs) wet weight

Brochure






DM560 Diesel Power Unit

DM560 Diesel Power Unit

Supports the 500 series of drifters and

rotary heads


  • 45 GPM @ 2500 PSI (170 lpm) of hydraulic flow


  • 100 HP (75 kw) Deutz Turbo tier IV engine


  • 2713 lbs (1230 kgs) wet weight

Hydraulic Drifters

TE1000

TE160HT

TE1000

Output power: 33 HP (25 kW)

Rotation torque: up to 10,000 lbf-ft (13,569 Nm)

Weight: 990 lb (449 kg)

TEI patented ASA percussion

Three (3) accumulators for smooth percussion

Shortest and lowest profile in its power class

Low pressure snubber cushion

Brochure

TE160

TE160HT

TE1000

Output power: 12 HP (9 kW)

Hole size: 1”-1 3/4” (25 mm – 45 mm)

Rotation torque: up to 106 lbf-ft (144 Nm)

Weight: 105 lb (48 kg)

TEI patented ASA percussion

High frequency percussion unit



Brochure

TE160HT

TE160HT

Output power: 12 HP (9 kW)

Rotation torque: up to 1000 lbf-ft (1357 Nm)

Weight: 171 lb (78 kg)

TEI patented ASA percussion

High frequency percussion unit

Unique, extremely short design



Brochure

TE260

TE260HT

Output power: 13 HP (10 kW)

Hole size: 1“-2” (25 mm – 52 mm)

Rotation torque: up to 200 lbf-ft (271 Nm)

Weight: 150 lb (68 kg)

TEI patented ASA percussion

High torque design for hollow bars

Brochure

TE260HT

TE260HT

TE260HT

Output power: 13 HP (10 kW)

Rotation torque: up to 1000 lbf-ft (1357 Nm)

Weight: 180 lb (82 kg)

TEI patented ASA percussion

High torque design

Compact design for drifting and tunneling

Brochure

TE326

TE260HT

TE260HT

Output power: 15 HP (11 kW)

Hole size: 1.5” – 3” (38 mm – 76 mm)

Rotation torque: up to 250 lbf-ft (339 Nm)

Weight: 178 lb (81 kg)

TEI patented ASA percussion

High power to weight ratio

Brochure

TE360

TE360

TE360

Output power: 15 HP (11 kW)

Rotation torque: up to 1475lbf-ft (2001 Nm)

Weight: 237 lb (107 kg)

TEI patented ASA percussion

Sleek low profile design

High power to weight ratio

Brochure

TE726

TE360

TE360

Output power: 30.5 HP (23 kW)

Hole size: 2” – 4” (52 mm -101 mm

Rotation torque: up to 616 lbf-ft (836 Nm)

Weight: 340 lb (154 kg)

TEI patented ASA percussion

Low torque for rock blastholes

Brochure

TE760

TE360

TE760

Output power: 30.5 HP (23 kW)

Rotation torque: up to 3000 lbf-ft (4071 Nm)

Weight: 530 lb (240 kg)

TEI patented ASA percussion

High torque hydraulic drifter

Fits most mid-sized anchor rigs

Brochure

Hydraulic Rotary Heads

RDS1004

RDS1004

RDS1004

Heavy duty hydraulic rotary head for drilling attachments and large drill rigs.

Rotation torque: up to 10,000 lbf-ft

(13,605 Nm)

Weight: 784 lb (356 kg)

Optional shock sub

Flange connection or thread output

Two (2)-speed rotary

Brochure

RDS1500

RDS1004

RDS1004

Lightweight, compact hydraulic rotary head.

Rotation torque: up to 15,000 lbf-ft

(20,408 Nm)

Weight: 974 lb (442 kg)

Optional shock sub

Flange connection

Three (3)-speed rotary


Brochure

RDS250

RDS1004

Lightweight, compact hydraulic rotary head for man-portable drills and limited access drills.

Rotation torque: up to 1000 lbf-ft (1361 Nm)

Weight: 106 lb (48 kg)

Optional shock sub

Flange connection or thread output

Two (2)-speed rotary


Brochure

RDS350

Lightweight, compact hydraulic rotary head for drilling attachments and limited access drills.

Rotation torque: up to 2000 lbf-ft (2721 Nm)

Weight: 122 lb (55 kg)

Optional shock sub

Flange connection or thread output

Two (2)-speed rotary

Brochure



RDS550

Hydraulic rotary head for drilling attachments and 3 to 6 ton drill rigs.

Rotation torque: up to 5000 lbf-ft (6803 Nm)

Weight: 390 lb (177 kg)

Optional shock sub

Flange connection or thread output

Two (2)-speed rotary

Brochure

TEI Limited Access Drills

Electric Track Drills

TD100

  • Work quickly, safely, and efficiently
  • Unique claws to clamp various sizes of pipe
  • Does not modify the excavator
  • Pick up casing and drill pipe simultaneously
  • Two 360 degree positioners to work both horizontally and vertically

Brochure



TD75

TD75

  • Limited access drill
  • 100 HP electric motor
  • 185 kW generator required
  • Rubber tracks can contract to 48 inches
  • 4 stabilizer jacks
  • Clamp and breaker system
  • 120-degree side to side mast rotation

Brochure

Man Portable Drills

MP250

MP250

Small, but still capable of installing a 75 kip micropile, soil nails, rock bolts, coring or hollow bars.


Uses TE160 or TE260 drifters

RDS250 rotary head

450 lbs.   204 kgs.

MP260

MP250

Small, but still capable of installing a 75 kip micropile, soil nails, rock bolts, coring or hollow bars.


Uses TE160 or TE260 drifters

RDS250 rotary head

450 lbs.   204 kgs.





Brochure

MPH Portable Drilling System

MPH Portable Drilling System

Pullback Force: 2500 lbf (11121 N)

Drill Travel: 6ft (SCF5) (2 m)

Weight: 960 lbs (435 kg)

Brochure

MT100 – Mountain Drill

The MT100 mountain drill is a completely new concept for slope stabilization. Built from customer demand for an electric/hydraulic-powered drill that can be safely lowered and raised from the top of a slope.


The four wheels provide a very stable base while the variable volume hydraulic reservoir allows the MT100 to drill at any angle. Even upside down.




50HP Electric Motor


Hydraulic Winch On-Board


Optional Radio Remote Controls

Brochure
